2.5 mm wall, and what it buys over span
Deflection rises steeply with span, so a profile wall that looks rigid at 900 mm can visibly bow at 1.4 m. A 2.5 mm wall keeps the sightline straight on wide leaves and lets the leaf carry a heavier glazing unit without the frame taking a permanent set. On a narrow leaf the extra wall is dead weight; on a wide one it is the difference between a flush face and a curved one.
